Wholesale M-225 5.5"PA Constant Voltage Wall Speaker Subwoofer 30w Wall Speake Hifi Conference Speaker

Home / Products / Hifi Conference Speaker / M-225 5.5"PA Constant Voltage Wall Speaker Subwoofer 30w Wall Speake Hifi Conference Speaker
M-225 5.5

01

Product category

M-225 5.5"PA Constant Voltage Wall Speaker Subwoofer 30w Wall Speake Hifi Conference Speaker

Features:

  • 5.5 inch 100V hifi conference wall speaker
  • With transformer 30W
  • TWO way wall speaker,25mm cone woofer,13mm silk film tweeter
  • Full white or full black

03

DATA INFORMATION

ITEM M-224 M-225 M-226 M-228
RMS POWER 20W 30W 35W 80W
MAX POWER 40W 50W 50W 100W
VOLTAGE INPUT 100V 100V 100V 100V
SENSITIVITY 91dB 91dB 92dB 92dB
FQ RESPONSE 75hz-19Khz 75hz-20Khz 75hz-20Khz 65hz-20Khz
LOUDSPEAKER 4“(Φ103mm)19/13mm cone 5.5“(Φ135mm)25/13mm cone 6.5“(Φ166mm)25/25mm cone 8“(Φ203mm)38/25mm cone
OUTSIDE SIZE 150×130×215mm 170×155×250mm 205×195×305mm 280×230×435mm
INNER BOX SIZE 150×140×268mm 180×165×305mm 215×200×360mm 335×295×500mm
TRANSFORMER SIZE 16×20 16×24 16×24 22×28
MATERIAL ABS ABS ABS ABS
COLOR BLACK/WHITE BLACK/WHITE BLACK/WHITE BLACK/WHITE
N.W. 1.85kg 2.6kg 3.32kg 6.36kg



04

PRODUCT DETAILS

05

installation drawings

How to install

  • Installation schematic:

  • Dimensions

  • Circuit schematic:

  • Wiring instructions:

    The amplifier output COM needs to be connected to the black wire when wiring, and the amplifier 100V output is connected to the required corresponding wire.

06

Packing


inner box


carton

Packing list

ITEM SIZE(cm) PCS/CTN CBM (m3) N.W. (kg) G.W. (kg) 20GP(pcs) 40HQ(pcs)
M-224 44*32*28.5 0.040  6 11.10  13.10  3900 9900
M-225 51.5*38*32.5 0.064  6 15.60  17.60  2436 6186
M-226 45*42*38 0.072  4 13.28  15.28  1444 3668
M-228 61.5*35.5*52 0.114  2 12.72  14.72  456 1158
